Fuchs Fricofin EVO Antifreeze

Fuchs Fricofin EVO Antifreeze is a Premium Performance coolant concentrate based on monoethylene glycol. Free of 2-EHA, nitrites, amines and borates with PSi-OAT technology. With BluEV Technology, additionally applicable in hybrid and electric vehicles of different manufacturers.

Description

FRICOFIN EVO is an antifreeze coolant concentrate based on monoethylene glycol and is
used for engines in Heavy Duty vehicles, passenger cars and stationary engines. Thanks to
its modern BluEV Technology formulation, the product FRICOFIN EVO is excellent for use for indirect cooling of hybrid and Battery Electric Vehicles (BEVs) in automotive and heavy-duty applications if there is no requirement on electrical conductivity. As PSi-OAT coolant, it combines organic inhibitors, which provide long change intervals with fast reacting silicates and phosphates for outstanding corrosion protection. FRICOFIN EVO is free of of nitrites, amines, and borates.

Application

FRICOFIN EVO was originally developed for conventional applications but additionally fulfills the requirements in selected hybrid and E-applications according to the manufacturers specifications. BluEV Technology therefore builds the bridge between existing and new lubricant applications. Excellent for use in cooling systems of various types of internal combustion engines.

FRICOFIN EVO is miscible with coolants approved as per VW TL 774- C (G11), TL 774-F (G12+), 774-G (G12++), 774-J (G13) and 774-L (G12EVO), however, to achieve a full performance a complete change is recommended. Always observe the manufacturers
recommendations when mixing with other coolants. FRICOFIN EVO is a coolant concentrate and must be diluted with water before it is filled into the cooling system.

The concentration rate should be between 33% to 60% by volume, typically 50%. The
properties of the water should not exceed the following limits:
Water hardness: 0 - 20 °dH (0-3.6 mmol/l)
Chloride content: 100 ppm max.
Sulphate content: 100 ppm max.
By adding distilled or deionized water these values can be easily adjusted, if necessary. Manufacturers’ drain intervals and recommendations about the concentration are mandatory. As with all coolants, even with FRICOFIN EVO , the use of galvanized components in cooling circuits and as a part of storage or mixing installation (e.g. for pipes) should be avoided.

Advantages

▪ Excellent fast-reacting protection against deposits, cavitation and corrosion in engines and cooling systems.
▪ Superior protection against freezing and overheating.
▪ Compatible with seals, plastics and non-ferrous metals.
▪ Contains bittering agent to prevent swallowing.
▪ Suitable for extended drain intervals.
▪ Contains a special additive to compensate for flux contamination from the CAB (Controlled Atmosphere Brazing) process.
▪ Excellent hard water stability.
▪ Thanks to BluEV Technology suitable for selected hybrid and electric vehicles.

Specifications

▪ AS/NZS 2108:2004 TYPE A
▪ ASTM D 3306 TYPE I
▪ ASTM D 4985
▪ BS 6580:2010
▪ CUNA NC 956-16
▪ PN-C40007:2000
▪ SAE J1034
▪ ÖNORM V 5123
▪ SANS 1251:2005
▪ China GB 29743-2013
▪ JIS K 2234:2006

Approvals

▪ DEUTZ DQC CC-14
▪ VW TL 774-L (G12EVO)

FUCHS Recommendations

▪ BMW LC-18, LC-97, LC-87
▪ MWM TR 2091
▪ VOLVO CARS (TR-31854114-002)

Colour: Pink/Violet

Please contact for all Technical Data and Safety information documents
